NGT - Manuel Reset Type
Type 04P Phenol Case
| Type | 04P |
| Operation Temp | 40℃ 〜 150℃ No self automatic reset. |
| Resetting by button | Auto reset less than -0℃ |
| Temp Tolerance | Standards：±3～10℃ ※Depend on Operation Temp |
| Max Ambient Temp | 150℃ |
| Resistance between Terminals | Less than 30mΩ (Initial value) |
| Insulation Resistance | Not less than 1,000MΩ/DC500V |
| Dielectric strength | Not less than AC1,500V/1min.
Not less than AC1,800V/1sec |
| Endurance | More than 10,000cycles (Standards) |
