Electrical Specifications
|
Feature
|
Units
|
R360/100
|
R430/80
|
|
Minimum supply voltage
|
VDC
|
11
|
|
Nominal supply voltage
|
VDC
|
85
|
68
|
|
Maximum supply voltage
|
VDC
|
94
|
75
|
|
Maximum continuous power output
(at 85VDC)
|
kW
|
25
|
|
Efficiency at rated power
(at 360A @ 85VDC, 430A@70VDC)
|
%
|
> 99
|
|
VCB supply voltage option
|
VDC
|
11 to 95
|
|
VCB power supply
|
VA
|
7
|
|
Continuous current limit (Ic) Amplitude
sinusoidal/DC trapezoidal commutation
|
A
|
360
|
430
|
|
Continuous RMS sinusoidal commutation
current limit (Ic)
|
A
|
254
|
304
|
|
Peak Current
|
A
|
No Peak
|
