Gold Drum 550 Highlights:

• Gold Line core motion control technology
• Delivers up to 550 A while operating from power voltage bus
• of 11VDC to 94 VDC
• Super compact package, weighs 3.6 kg,
• dimensions 195 x 222 x 100mm
• Operates from a 12 to 95 VDC source DC power source
• Operates in current, velocity, position and advanced position modes, in conjunction with a permanent-magnet synchronous brushless motor, DC brush motor, linear motor or voice coil
• Advanced and extremely fast vector control algorithm (current loop bandwidth: 4 kHz)
• Highly efficient, high bandwidth performance
• Multiple communication options: EtherCAT (or EtherCAT with switches), CANopen, RS-232, RS-422 USB, Ethernet
• Supports a wide variety of feedback: Incremental, Encoder, Resolver, Digital Halls, Analog Halls, Analog 1V PTP (Sin/Cos), Absolute Serial Encoders, Potentiometer
• Advanced filtering and gain scheduling options for enhanced dynamic performance
• Easily optimized set up and tuned using Elmo Application Studio (EAS) software tools
• 6 digital inputs and 4 digital outputs – Supports PLC Source, PLC Sink and TTL I/O types
• Complies  with the strictest Safety, EMC and environmental standards.

Electrical Specifications
