Electrical Specifications
|
Feature
|
Units
|
2.5/100
|
5/100
|
10/100
|
15/100
|
20/100
|
|
Minimum supply voltage
|
VDC
|
12
|
|
Nominal supply voltage
|
VDC
|
85
|
|
Maximum supply voltage
|
VDC
|
95
|
|
Maximum continuous power output
|
W
|
200
|
400
|
800
|
1200
|
1600
|
|
Efficiency at rated power (at nominal conditions)
|
%
|
> 99
|
|
Maximum output voltage
|
|
> 95% of DC bus voltage at f=22 kHz
|
|
Auxiliary power supply
|
VDC
|
11 – 95 VDC (up to 2.5 VA inc. 5 V/200 mA for encoder)
|
|
Amplitude sinusoidal/DC continuous current
|
A
|
2.5
|
5
|
10
|
15
|
20
|
|
Sinusoidal continuous RMS current limit (Ic)
|
A
|
1.8
|
3.5
|
7
|
10.6
|
14.1
|
|
Peak current limit
|
A
|
2 x Ic
|
|
Weight
|
g (oz)
|
479 g (16.9 oz)
|
|
Dimensions
|
mm (in)
|
150 x 105 x 25.8 mm (5.9" x 4.13" x 1")
|
|
Digital in/Digital out/Analog in
|
|
6/4/1
|
|
Mounting method
|
|
Wall mount, Book Shelf
|
