NGT - Splash - Water Proof Type
Type MH4 PBT Cover
| Type | MH4 |
| Operation Temp | 0℃ 〜 70℃ |
| Differential | Standards：10K 〜 20K |
| Temp Tolerance | Standards：±3～10℃ ※Depend on Operation Temp |
| Max Ambient Temp | 70℃ |
| Resistance between Terminals | Less than 50mΩ (L=120mm) (Initial value) |
| Insulation Resistance | Not less than 1,000MΩ/DC500V |
| Dielectric strength | Not less than AC1,500V/1min.
Not less than AC1,800V/1sec |
| Endurance | More than 10,000cycles (Standards) |
