Type MH5 PPS Cover

NGT - Splash - Water Proof Type
Type MH5 PPS Cover

Type MH5
Operation Temp 20℃ 〜 100℃
Differential

Standards:10K 〜 30K

Temp Tolerance Standards:±5~10℃ ※Depend on Operation Temp
Max Ambient Temp 100℃
Resistance between Terminals

Less than 30mΩ(Initial value)

Insulation Resistance Not less than 1,000MΩ/DC500V
Dielectric strength Not less than AC1,500V/1min.
Not less than AC1,800V/1sec
Endurance More than 10,000cycles (Standards)
NGT - Type MH5 PPS CoverNGT - Type MH5 PPS Cover

03型フェノールケース

  • Compliance with RoHS Directives.
  • Splash proof equivalent to IP64.
  • Please feel free to ask us in case that operation temp, Diffential, Temp Tolerance is not standard.
