Features

• Through bore size 3mm to 500mm
• Circuit number from 2-350
• Operation speed: standard up to 250rpm
• Circuit current: 2A, 5A, 10A, 15A, 20A, 50A, 100A, 200A, up to 400A.
• Power circuit and Ethernet signal circuit can be integrated to one unit slip ring
• Standard housing is ABS material up to bore size60mm , AL housing offered the bore size bigger than 70mm
• Flexible, color-coded, silver-plated, Teflon® insulated lead wires
• Contact material silver to silver coating
• Standard wire leads length is 500mm
• Standard temperature is -20°C to +80°C
• Insulation strength 500V AC@50HZ 60S
• Insulation resistant  500MΩ 500VDC
• Long life cycles up to 80 million cycles
• Protection grade IP 51, IP54, IP 65
• Ethernet circuits can transmission 100Mbps, 1Giga data.
• Cable gland exit

Options

• Bore size
• Circuit number
• Current
• Operation speed up to 3000rpm
• IP grade
• Slip ring structure material, AL, SS
• Wire lead length, direction, position
