Features

• Combine the pneumatic hydraulic rotary joint with electric slip rings
• Circuit number from 2-350
• Operation speed: standard up to 250rpm
• Circuit current: 2A, 5A, 10A, 15A, 20A, 50A, 100A, 200A, up to 400A.
• Power circuit and Ethernet signal circuit can be integrated to one unit slip ring
• Flexible, color-coded, silver-plated, Teflon® insulated lead wires
• Contact material silver to silver coating
• Standard wire leads length is 500mm
• Standard temperature is -20°C to +80°C
• Insulation strength 500V AC@50HZ 60S
• Insulation resistant  500MΩ 500VDC
• Long life cycles up to 80 million cycles
• Protection grade IP 51, IP54, IP 65
• Ethernet circuits can transmission 100Mbps, 1Giga data.

Optional

• Material AL or SS
• Flange mounted
• Rotary speed
• Air or liquid pressure
