Marathon SP Bulk Fastening Power Blocks (BFPB)
The BFPB Series is a single pole design that consists of a series of stud fasteners to allow you to terminate various combinations of crimp lugs or flexible bus bar with one configuration. The series is ideal for use with flexible stranded wire terminations or large and abnormal wiring combinations.

Electrical
•    1605 amps
•    1000 volts AC/DC (cULus)
•    Multiple wire rating - refer to data sheets for details
•    Provides feeder circuit terminal spacing
Mechanical
•    Insulator - thermoplastic: 125°C (257°F) - UL RTI
•    Flammability, UL 94 V-0
•    Mounting: panel mountable
Features / Benefits
•    Modular construction to accommodate numerous terminal options
•    Available for 2 to 6 stud terminal positions
•    Accommodates power distribution options for listed lugs sized up to 1000kcmil
•    First power terminal block to have a high SCCR rating (35k) with no over current protection device
•    Reliably terminates flexible stranded classes of wire with crimp lugs
•    Suitable to terminate and distribute power with flexible bus bar
Standards
•    UL recognized file no. XCFR2.E62806 (UL 1059)
•    cUR recognized file no. XCFR8.E62806 (UL 1059)
•    RoHS compliant (all)
