Studded power blocks are part of our traditional NEMA style offering. These power blocks provide studs, or a combination of bare wire terminals with the stud, to terminate crimp lugs or bus bar to our power blocks to splice or distribute power.

Electrical
• 115 - 1680 amps
• 600 volts AC/DC (UL)
• Flexible stranded wire compliant
• Multiple wire rating - refer to data sheets for details
Mechanical
• Base, black thermoplastic or phenolic (see chart)
• Insulator temp-ratings
• Thermoplastic: 125°C (257°F) - UL RTI
• Phenolic:150°C (302°F) - UL RTI
• Flammability, UL 94 V-0
• Mounting: panel mountable, 132 series is also DIN mountable
Standards
• See datasheets for product specific approvals listed
• UL recognized file no. XCFR2.E62806 (UL 1059)
• CSA certified file no. LR19766 (CSA C22-2 No. 158)
• RoHS compliant (all)

**Power Blocks - Stud Configurations**
Amper	Catalog #	Poles (X)	MATERIAL		LINE SIDE		LOAD SIDE
Amper	Catalog #	Poles (X)	Insulator	Conn.	Wire Range AWG / kcmil -or- Stud Size	Connector Openings / Pole	Wire Range AWG / kcmil -or- Stud Size	Connector Openings / Pole
115	141x203	1/2/3/4	Plastic	AL	#2 - #14	1	#10-32 X .60	1
175	132x574	0/1/2/3	Plastic	AL	2/0 - #14	1	1/4-20 x .50	1
	132x474	0/1/2/3	Plastic	AL	2/0 - #14	1	M6 X 13	1
	142x574	1/2/3	Phenolic	AL	2/0 - #14	1	1/4-20 X .50	1
	143x590	1/2/3	Phenolic	AL	2/0 - #14	1	1/4-20 X 1.38	1
200	132x122	0/1/2/3	Plastic	CU	1/4-20 X .56	1	1/4-20 X .56	1
	132x422	0/1/2/3	Plastic	CU	M6 X 15	1	M6 X 15	1
	142x122	1/2/3	Phenolic	CU	1/4-20 X .56	1	1/4-20 X .56	1
230	143x563	1/2/3	Phenolic	CU	3/8-16 x 1.18	1	3/8-16 x 1.18	1
	143x561	1/2/3	Phenolic	CU	3/8-16 x 1.18	1	1/4-20 x 1.38	1
	144x553	1/2/3	Phenolic	CU	3/8-16 x 1.44	1	3/8-16 x 1.44	1
260	144x122	1/2/3	Phenolic	CU	3/8-16 x 1.44	1	1/4-20 X .56	2
310	133x564	1/2/3	Phenolic	CU	M10 x 30	1	M10 x 30	1
	133x563	1/2/3	Phenolic	CU	3/8-16 x 1.18	1	3/8-16 x 1.18	1
	143x559	1/2/3	Phenolic	AL	350 - #6	1	3/8-16 x 1.13	1
	133x559	1/2/3	Phenolic	AL	350 - #6	1	3/8-16 x 1.25	1
	133x558	1/2/3	Phenolic	AL	350 - #6	1	M10 x 30	1
360	145x573	1/2/3	Phenolic	CU	3/8-16 x 1.44	1	3/8-16 x 1.44	2
360	145x583	1/2/3	Phenolic	CU	3/8-16 x 1.44	1	1/4-20 x 1.44	2
380	144x569	1/2/3	Phenolic	AL	500 - #4	1	1/4-20 x 1.06	2
380	144x575	1/2/3	Phenolic	AL	500 - #4	1	3/8-16 x 1.31	1
410	145x606	1/2/3	Phenolic	CU	1/2-13 x 1.44	1	1/2-13 x 1.44	1
410	133x611	1/2/3	Plastic	CU	1/2-13 x 1.38	1	1/2-13 x 1.38	1
475	145x613	1/2/3	Phenolic	CU	3/8-16 x 1.44	2	3/8-16 x 1.44	1
510	133x272	1/2/3	Plastic	AL	3/8-16 x 1.19(a)	1	4 - #14	12
	133x280	1/2/3	Plastic	AL	3/8-16 x 1.19(a)	1	#2 - #14	8
	133x270	1/2/3	Plastic	AL	3/8-16 x 1.19(a)	1	2/0 - #14	4
760	145x282	1/2/3	Phenolic	AL	3/8-16 x 1.00	2	2/0 - #14	8
	145x599	1/2/3	Phenolic	AL	500 - #4	2	3/8-16 x 1.31	2
	145x610	1/2/3	Phenolic	AL	500 - #4	2	1/2-13 x 1.31	1
840	144x614	1/2/3	Phenolic	CU	3/8-16 x 1.00	1	3/8-16 x 1.00	1
1680	145x615	1/2/3	Phenolic	AL	600 - #4	4	1/2-13 x 1.56	1
