NGT - Otomatik Reset Tip Bimetal Termostat
Polyester Kasa Model 21
| Type | 03P&03E |
| Operation Temp | 0℃～ 150℃ |
| Differential | Standards：10K～30K |
| Temp Tolerance | Standards：±3～10℃ ※Depend on Operation Temp |
| Max Ambient Temp | 150℃ |
| Resistance between Terminals | 03PP・03EP ：Less than 10mΩ(Initial value)
03PN・03EN・03PC ：Less than 30mΩ (Initial value) |
| Insulation Resistance | Not less than 1,000MΩ/DC500V |
| Dielectric strength | Not less than AC1,500V/1min.
Not less than AC1,800V/1sec |
| Endurance | More than 10,000cycles (Standards) |
• Anti Tracking CT600V
• Compliance with RoHS Directives
• This is not splash or water proof type
• Please feel free to ask us in case that operation temp, Diffential, Temp Tolerance is not standard.
