MFO600

MFO600 - Fiber Optik Slip Rings
MFO600 slip rings are standard, off-the-shelf. It could support 6 channel fiber optics(SM/MM) transmitting on 360° rotating.The rugged body allows fiber pigtail, FC receptacles on either the rotor side or the stator side.features extremely low insertion loss and impressive return loss performance for both singlemode and multimode fibers.MFO600 are often used with electronic sliprings, call optical-electrical hybrid slipring, transmit power and high speed data.

MFO600
PART # WAVELENGTH CHANNEL INSERTION LOSS LEAD LENGTH CONNECTORS
MFO600 650nm~1310nm 4 channel SM/MM <2dB @ each 1000mm FC
MFO600(1channel FORJ) Specifications
Wavelength(All Channels) 650nm~1310nm Insertion loss(All Channels) <2.0dB (normal: <0.8dB)
Insertion loss ripple <+/-0.25 dB Return loss (SM/MM) >40 dB(RFC/RST)
Maximum speed 2000 RPM Pressure compensation 1000 psi
Pulling strength. 10N Start up torque 0.1N/m
Estimated life cycle 300 million Optical power handling 23 dBm
Working temperature -40 to 85 °C Storage temperature -50 to 85 °C
Package style FC Housing materia Stainless steel
Fiber types Support both SM/MM Connector FC, SC, ST, SMA, or LC
IP rating IP 68 Weight 50g
Lead length 1000mm




MFO600 - Fiber Optik Slip Rings

Typical Application

  • between in undersea robot and control ship.
  • between in radar antenna and on-board signal processing system.
  • with the chariot rotating tower car body console.
  • between in welding robot and console.
